Digital Oscilloscope 50 MHz 2 channels portable UT1050DL

Availability:

S’ka stok


The UNI-T UTD1050DL is a versatile digital storage oscilloscope featuring 2 channels, 50 MHz bandwidth, and a built-in digital multimeter. Ideal for engineers and professionals.



65,000 L

S’ka stok

UNI-T UTD1050DL Digital Oscilloscope Description

The UTD1050DL is a high quality, portable digital storage oscilloscope, which combines the functionality of a 2 channel digital oscilloscope with an analog bandwidth of 50 MHz and a sampling rate of 250 MS/s with that of a digital multimeter. The instrument can be operated with the built-in rechargeable battery or with a power supply unit. Due to the wide range of functions as well as the attractive price, the UTD1050DL digital oscilloscope is very popular among engineers and other professional users.

The UT1050DL complies with all EU safety standards.

UNI-T UTD1050DL Digital Oscilloscope Features

  • 2 channels
  • 50 MHz analog bandwidth, sampling rate 250 MS/s (real time)
  • Auto setup and auto scale functions, making instrument setup a breeze
  • Extensive display and analysis functions for signal evaluation; Isolated USB interface for further evaluation of data on a computer
  • Cursor control and evaluation functions
  • High measurement resolution (up to 20 V/div)
  • 3.5″ LCD color screen with a resolution of 320 x 240 pixels; screen can be switched to b/w display
  • Various triggering options: Edge, pulse width, video, slope
  • Screen image (also multimeter) can be stored (memory function)
  • Signal waveforms can be recorded and played back using a recorder function
  • Digital multimeter with automatic range selection (Auto Range) for AC/DC voltage measurement up to 400 V, AC/DC current measurement up to 6 A, resistance measurement up to 40 MOhm, capacitance up to 100 µ
  • Other functions multimeter: Continuity test, diode test, data hold function, relative value measurement
